Legend Suspension Revo-a Adjustable M-eight Softail Coil Suspension

Experience superior ride comfort and enhanced performance with the Legend Suspension REVO-A coil suspension system, designed specifically for M-Eight Softail models. This adjustable coil suspension delivers unmatched handling and bike control, transforming your ride into a smooth and responsive experience. Built for enthusiasts and professionals alike, the REVO-A system is engineered for all-day comfort and lasting performance.

Description

The Legend Suspension REVO-A coil suspension system provides an exceptional riding experience thanks to its innovative design and high-quality components. Available in 12.5", 13", and 13.5" lengths, this system offers standard or heavy-duty applications to suit your specific needs. The REVO-A coil spring ensures superior ride comfort and improved performance while increasing resistance to bottoming out, providing all-day comfort. Its adjustable preload allows for personalized rider setup and minimal adjustments when changing between rider weights and loads. Seven external knob adjustments enable fine-tuning of rebound utilizing needle valve technology, adapting precisely to your riding style. The 46 mm mono tube, crafted from hard anodized, machined billet aluminum, features a lightweight high-flow piston design, which improves fluid flow for unmatched handling and control. The hard chromed shaft, 14% larger for increased strength, along with the high-quality chrome-silicon spring, ensures a consistent spring rate and long-lasting durability. Internal floating nitrogen piston and deflective disc valving self-adjust to frequency, ensuring controlled performance. Legend's durable, low-friction sealing system and sliding bearings further enhance performance and feel. The shock is finished with a black Type III hard coat anodize. Easy installation and adjustment replace the stock shock using original OEM hardware.

Features & highlights

• Experience superior ride comfort and performance with the innovative Revo-A coil design tailored for M-Eight Softail models.
• Enjoy a fine-tuned ride with seven external rebound adjustments, adapting to your riding style using advanced needle valve technology.
• Customize your setup with adjustable preload, accommodating varying rider weights and loads effortlessly.
• Benefit from enhanced handling and control thanks to the 46 mm monotube, crafted from hard-anodized billet aluminum with a lightweight, high-flow piston.
• Rely on the 14% larger, hard-chromed shaft and high-quality chrome-silicon spring for consistent spring rate and lasting durability.
• Ensure consistent damping performance with the internal floating nitrogen piston and deflective disc valving that self-adjusts to frequency.
• Enjoy ease of installation and smooth operation with low-friction sleeve bearings that allow the shock to float freely, preventing binding.

Technical specifications

• Brand: Legend Suspension
• Vendor Part Number: 1310-2315
• Adjustment Type: Adjustable Rebound Damping
• Color/Finish: Black, Anodized
• Duty: Standard
• Extended Length: 13.50" (343.00 mm)
• Material: Billet Aluminum
• Mounting Position: Rear
• Product Name: Shock Absorber
• Reservoir Location: Internal
• Type: Coilover Monotube
• Units: Each

Important to know

Sold as Mono Shock (1 shock only). Preload wrench included. Designed for optimum performance with the Legend Axeo front suspension.
